Linear Barcode Plus QR Code Scanner
The DuraSled™ DS820 is a linear barcode & QR Code scanner sled for 1D/2D barcodes, with Bluetooth® wireless technology for Apple iPhones and iPods. The DuraSled reads printed or on-screen barcodes. It is easy-to-use and ideal for delivery services, asset tracking, ticketing, and other application-driven mobile solutions. Its case protects phones from drop damage and provides simultaneous charging of the scanner and the phone.
The Capture SDK enables easy integration into native, and/or web-based applications that use scanning to enhance the productivity of workers using iPhones.
- General Information
- Manufacturer
- Socket Mobile, Inc
- Manufacturer Website Address
- http://www.socketmobile.com
- Brand Name
- Socket Mobile
- Product Line
- DuraSled
- Product Type
- Barcode Scanner
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Connectivity Technology
- Wireless
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
- 1D:
- Codabar
- Code 39
- Code 93
- Code 128
- EAN-13
- EAN-8
- Interleaved 2 of 5
- ISBT 128
- UPC A
- UPC E1
- Chinese 2 of 5
- Codabar
- Code 11
- Code 16KCode 39
- Code 93
- Code 128
- Discrete 2 of 5
- EAN-13
- EAN-8
- GS1 Databar
- Industrial 2 of 5
- Interleaved 2 of 5
- Matrix 2 of 5
- MSI Plessey
- UPC A
- UPC E1
- Standard 2 of 5
- UK Plessey
- Data Matrix
- Micro QR Code
- PDF417
- QR Code
- Aztec
- Data Matrix
- Han Xin
- Micro PDF417
- Micro QR Code
- PDF417
- QR Code
- Image Sensor Type
- Linear
- Scan Pattern
- Omni-directional
- Scanning Distance
- 380 mm
- Field of View (Horizontal)
- 45°
- Field of View (Vertical)
- 34°
- Maximum Ambient Light
- 100000 lux
- Drop Specification
- Multiple drops to vinyl covered concrete at about 3 ft or 1 m
- Minimum Print Contrast
- 25%
- Maximum Element Resolution (Code 39)
- 0.13 mm
- Maximum Element Resolution (DataMatrix)
- 0.25 mm
- Network & Communication
- Bluetooth
- Yes
- Interfaces/Ports
- Host Interface
- USB
- Battery Information
- Battery Weight
- 12.5 g
- Physical Characteristics
- Height
- 28.7 mm
- Width
- 74.9 mm
- Length
- 171.5 mm
- Weight (Approximate)
- 113.5 g
- Miscellaneous
- Package Contents
- DS820 barcode sled scanner
- GDS Charging Dock
- USB Charging Cable
- 1 year limited Warranty on DuraSled and charging dock
- Compatibility
- Apple - iPhone 11 , iPhone XR
- Ingress Protection (IP) Rating
- IP40
- Application/Usage
- Retail
- Hospitality
- Logistics
- Healthcare
- Inventory
- Transportation
- Warehouse
- Field Sales/Service
- Platform Supported
- iOS
- Country of Origin
- United States
- Environmentally Friendly
- Yes
