Teltonika Combo Siso Mobile/GNSS/WIFI Flush Mount Mobile Antenna For Vehicle/Cabinet - For Use With Rut950 - Formerly 003R-00254

  • Part: 1204884
  • Model: PR1KCS28
$59.09

Availability

In Stock

Teltonika Combo SISO Mobile/GNSS/WIFI Roof SMA Antenna GNSS Antenna Frequency Range: 1575.42-1610 MHz Polarization RHCP Impedance 50 Ω LNA Gain 28 dB LNA Noise Figure < 1.5 dB Supply Voltage 2.7-5 ±0.5 VDC Current Consumption < 15 mA LNA V.S.W.R <1.65 Connector SMA Male LTE Antenna Frequency Range: 850/900/1800/1900/2170 MHz Bandwidth ±90/280 MHz Polarization Vertical Gain 3.5 dBi V.S.W.R: <1.5:1 Impedance: 50 Ω Connector: SMA Male WiFi Antenna Frequency Range: 2350-2500 MHz Bandwidth ±100 MHz Polarization Vertical Gain 2.5 dBi V.S.W.R: <1.5:1 Impedance: 50 Ω Connector: RP SMA Male Mechanical/Environmental Mounting Method: Screw Radome Ingress Protection rating: IP67 Radome Material: ABS Weight: <250g Housing Dimensions: Ø 80x15 mm Cable: 3x RG174, 3000 mm RoHS Compliant: ✔
